Mr LuyếnList code Magtrol Vietnam
1. Model: 224-212-011 - LMU 212/011 Magtrol
LOAD MONITORING UNIT /2 LEV
Load monitoring unit with 2 sensor input,
2 O/P 4-20 mA and 2 O/P 0-10 V
Power supply 18…32 VDC
2. P/N: 006249
Model: AHB-12
BRAKE, AIR COOLED, 24V
Rated torque 12 Nm
Max braking power 2,800 W
Max speed 12,000 rpm
24 Volt Coil
This unit requires 620 KPa (90 psi) @ 20 SCFM for proper cooling
3. P/N: 005676 Magtrol
Model: AHB-1
BRAKE, AIR COOLED, 24V
Rated torque 1.0 Nm
Max braking power 1,200 W
Max speed 25,000 rpm
24 Volt Coil
This unit requires 620 KPa (90 psi) @ 20 SCFM for proper cooling
4. P/N: 007714 Magtrol
Model: HD-715-5C2-0100
DYNAMOMETER, 240 VAC, 60 PPR, SHORT
Rated torque 6.20 Nm (0-5 Vdc output)
New connectors
Short Base Plate
Max braking power 3,400 W
Max speed 25,000 rpm
Blower Cooled
Encoder 60 PPR
*NOTE: The quotation just quoted DYNAMOMETER only
Please check what controller and cable will this dyno be used with as without them the equipment cannot be uses
5. P/N: 88M370-0500 Magtrol
Model: CABLE ASSY,M12-4F/CINCH 2M,5m
BRAKE CABLE, M12-4F TO CINCH-2M
*Note: Cable set for use with an existing DSP7000 series controller
6. P/N: 88M372-0500 Magtrol
Model: CABLE ASSY, D-SUB 15F/14P AMPHENOL, 5m
SIGNAL CABLE, D-SUB 15F TO MICRO-RIBBON-14
*Note: Cable set for use with an existing DSP7000 series controller
7. Model: 843-102-000-011
CTS 102 COGGING TEST SYSTEM 200mNm Magtrol
Cogging Test System
Measuring range: 0 - 200 mNm
Accuracy: 0.05% of rated torque
Speed: 1 - 10 rpm
Shaft height: 100 mm
Mounted on PT-25 base, length 600 mm
With USB interface
Incl. Control and Data Acquisition Software (LabVIEW exe)
8. Model: 424-102-000-211
TS 102/211 0.2Nm 5000PPR
Torque Sensor with smooth shaft
Analog and USB outputs
Rated Torque 0.2 Nm, Accuracy <0.05%
Max Measurable Torque 0.4 Nm
Max speed 1000 rpm
With 5000 Bits Encoder (A, B, Z)
Incl. 3 m. analog and 2 m. USB cables
9. Model: 843-105-000-011
CTS 105 COGGING TEST SYSTEM 2Nm
Cogging Test System
Measuring range: 0 - 2Nm
Accuracy: 0.05% of rated torque
Speed: 1 - 10RPM
Shaft height: 180mm
Mounted on PT-25 base, length 800 mm
With USB interface
Incl. control and data acquisition software (LabVIEW exe)
10. Model: 424-105-000-211
TS 105/211 2Nm 5000PPR Magtrol
Torque Sensor with smooth shaft
Analog and USB outputs
Rated Torque 2 Nm, Accuracy <0.05%
Max Measurable Torque 4 Nm
Max speed 1000 rpm
With 5000 Bits Encoder (A, B, Z)
Incl. 3 m. analog and 2 m. USB cables
11. P/N: 317-101-900-021 Magtrol
Model: 1WB32 Magtrol
EDDY CURRENT SYSTEM, WITH FIXTURE, 0.4 Nm
1WB32 High Speed Eddy Current Dynamometer
Rated torque 0.4 Nm at 11,950 rpm
Power rating: 500 W
Maximum speed 80,000 rpm
With integrated Torque-Speed measurement
With integrated dyno excitation suppy
Mounted on 765mm T-Slots base plate
With AMF-1 motor fixture
with protection guard including closing contact
As per drawing 317-101-000V011
12. P/N: 88M368-0500 Magtrol
CABLE, D-SUB 15M/D-SUB 15F, 5.0m, SHIELDED
SIGNAL CABLE, D-SUB 15M TO D-SUB 15F, SPECIAL
13. P/N: 957-18-25-0301 Magtrol
EXCITATION CABLE L=5m FOR WB 32 + DSP701X
14. P/N: 007941 Magtrol
Model: DSP7011 Magtrol
CONTROLLER, 1-CHANNEL (GPIB, USB, 1 I/O)
High-Speed Programmable Dynamometer
Controller, Single Channel, USB Interface,
GPIB Interface, Single I/O Card
15. P/N: 954-21-11-0126 Magtrol
Model: MIC-5-0039 10H7/10H7 Magtrol
COUPLING, 10mm - 10mm 20K RPM
